Plan 23-047
Copyright by Designer
Square Feet
4383
Bedrooms
4
Bathrooms
4
Garage Stalls
3
Floors
1
Half Baths
2
Width
101' 11"
Depth
98' 9"
Height
1'
Square Feet
4383
Bedrooms
4
Bathrooms
4
Garage Stalls
3
Floors
1
Half Baths
2
Width
101' 11"
Depth
98' 9"
Height
1'
Expert Plan Review
Before you build, get clarity. Our seasoned design team is ready to provide authoritative answers on techinal specifications and custom modifications.
Design Your Home
Need changes to make this plan truly yours? Get a quick, free estimate and personalized advice – let’s personalize this design to fit your specific needs today.
Design Your Home
Need changes to make this plan truly yours? Get a quick, free estimate and personalized advice – let’s personalize this design to fit your specific needs today.
Expert Plan Review
Before you build, get clarity. Our seasoned design team is ready to provide authoritative answers on techinal specifications and custom modifications.
Plan 23-047
Starting at
$1,740.00
$1,740.00
Features
Square Footage
Dimensions
Details
Style
Texas Hill Country, Contemporary Rustic, Modern Craftsman RanchOutdoor Features
Front Porch, Rear Porch, Outdoor Fireplace, Outdoor KitchenBedroom and Bath Options
Bedrooms – Split, Master Bedroom at RearKitchen and Dining
Breakfast Nook, Kitchen Island, Open Floor Plan, Walk-In Pantry, Formal DiningLaundry Location
Access From Master SuiteAdditional Rooms
Flex Room, Study/OfficeGarage Type
Side EntryFoundation Type
Slab, Crawl Space, BasementPlan Description
Stepping into Plan 23-047 is like embracing a warm, luxurious hug after a long day. Imagine pulling up to your Modern Craftsman Ranch, a beautiful Texas Hill Country-inspired home where rugged natural stone meets smooth stucco under a dark charcoal metal roof. The timber-framed porch, supported by grand stone-clad pillars, welcomes you and your loved ones with open arms.
As you enter, the foyer unfolds into a spacious great room with a soaring cathedral ceiling and a cozy fireplace, beckoning you to unwind. The seamless flow into the open-concept kitchen and casual dining area makes it easy to connect with family and friends while preparing meals or sharing stories.
The left side of the home is your private sanctuary. The master suite, tucked away for ultimate peace, features a bedroom with a tray ceiling and its own fireplace. The ensuite master bath is a spa-like retreat, complete with dual vanities, a generous shower, and a soaking tub that promises relaxation. And the walk-in closet? A dream come true, with space for everything and more. The relationship between the Master Bedroom, Master Bathroom, and Master Closet is one of intimate connectivity, designed for seamless transitions and ultimate convenience, enhancing your daily routine with a touch of luxury.
On the other side of the home, the game room buzzes with potential for fun and laughter, while additional bedrooms offer comfort and privacy for family or guests. The massive garage stands ready to house your vehicles and hobbies, and the expansive outdoor living area, with its own fireplace, extends the invitation to relax and enjoy the beauty of nature.
This home isn't just a place to live; it's a place to thrive, to create memories, and to experience the best that life has to offer. With its thoughtful design, high-end finishes, and seamless blend of indoor and outdoor living, Plan 23-047 is more than a house plan; it's the blueprint for your dream home.
What's Included
Floor Plan: Complete dimensions. Provides designation of all rooms, closets, cabinets, stairs, etc. Windows and doors clearly indicated with sizing and door swing direction. Permanently installed equipment indicated (cabinets, built-ins, plumbing fixtures, HVAC units).
Foundation Plan: Provides Complete dimensions. Slab layout and details where applicable. All concrete footings, pad, foundation wall and grade beams are shown.
Elevations: Front, Rear, Left and Right-side exterior elevations. Indicates all exterior finish materials. Finished floor lines with vertical dimensions. Shows all window and door openings.
Roof Plan: Perimeter rooflines, hip, valley, and ridge locations. All roof pitches, overhangs and necessary dimensions.
Wall Sections: Full wall section through house. Necessary Framing Details.
Schedules: Door and Window sizes, Room Finishes and information.
Cabinet Elevations: Elevations of all cabinetry.
Electrical: Indicates schematic layout of all outlets, switches and fixtures.
What's Not Included
Stamps: Depending on the city, county, and state building requirements, house plans may need to be reviewed by an architect or engineer for structural details and code standards. Contact a local architect or engineer to verify the requirements for your location.
Site Plan: A site plan shows how the house will fit on the lot between the property lines and the setbacks. It also shows the driveway and where parking, drainage easements, utility easements, and walkways should be constructed. Contact a civil engineer or surveyor to obtain the site plan.
Mechanical Drawings: These types of drawings show information about heating, ventilation, and air conditioning. Contact a local HVAC company to obtain mechanical drawings.
Plumbing Drawings: Plumbing drawings show the location of all plumbing materials throughout the house and outside. Contact a local plumbing contractor.
Energy Calculations: Energy calculations determine how energy efficient your new home will be. Contact a local engineer to dictate these calculations.
